20,000 lb Coe Feedline For Sale
20,000 lb Coe Feedline Specifications
- Model: NCHF-40
- Serial: 35584-1
- Year of Manufacture: 2004
- Coil Weight Capacity: 20,000 lbs
- Coil I.D.: 20"-24"
- Coil O.D.: 72" Max
- Expansion Type: Wedge Type Hydraulic Cylinder
- Material Specifications:
- High-Strength Low-Alloy Steel (HSLA)
- HSLA 50K Yield (Max): .250" Thick @ 18" Wide
- HSLA 50K Yield (Min): .020" Thick @ 36" Wide
- HSLA 50K Yield (Max): .187" Thick @ 36" Wide
- Straightening Capacity:
- Pinch Rollers: 2 Rolls - 4.42" Dia.
- Feeder Rollers: 2 Rolls - 5.66" Dia.
- Straightener Rollers: 7 Rolls - 3.36" Dia. - 4 Over 3
- Performance Specifications:
- Feed Velocity: 200 FPM
- Feed Acceleration: 20 Feet/Second/Second
- Feed Accuracy: +/- .005"
This machine is used and is being sold as is with no warranty. Some machines may qualify for a 3rd party warranty, please ask. As this is a used machine, we do not offer any refunds or returns.
Please call or email us for more information.
Phone: (+52) 442-825-0074
Phone: (+52) 442-323-7736
Email: info@sgmachinery.net
PLEASE NOTE: The shipping & loading cost is at the buyer's expense (for some reason, we can't specify that with this eCommerce system). The machine is being sold "as is".
